Overview
The HT42B564-x device is a high performance USB to UART bridge controller with fully integrated USB and UART interface functions, designed for applications that communicate with various types of UART. The device includes a USB 2.0 full speed compatible interface which is used for PC communication. The device also includes a fully integrated high speed oscillator which is used as clock source for the USB and UART baud rate generator. The baud rate generator can support up to 115200bps of baud rate for the UART interface.
Documents
HT42B564-xv120
Contains electrical characteristics, register descriptions, and system architecture. Please refer to it before solution design and software development.
10SOP
Includes package dimensions, pad layout, and assembly requirements. Please use it for PCB layout and process evaluation.
