Overview
The BH45B1225 is a multi-channel 24-bit Delta Sigma A/D converter which includes a programmable gain amplifier and is designed for applications that interface differentially to analog signals. The device has the benefits of low noise and high accuracy and communicates with external hardware using an internal I2C bus. This highly functionally integrated Delta Sigma analog to digital converter with its high accuracy and low power specifications offers a superior solution for interfacing to external sensors especially for battery powered applications.
Documents
BH45B1225v140
Contains electrical characteristics, register descriptions, and system architecture. Please refer to it before solution design and software development.
8SOP
Includes package dimensions, pad layout, and assembly requirements. Please use it for PCB layout and process evaluation.
